Acid Gas Control Systems

PCC designs wet acid gas control systems that absorb SO₂, HCl, and HF and other halogenated acid gases.

Acid gas control removes sulfur oxides (SOx), hydrogen chloride (HCl), and hydrogen fluoride (HF) from process exhaust by absorbing them into an alkali liquid using a variety of alkaline based solutions. The appropriate absorber and reagent depend on which acid gases are present, how hot and dusty the gas is, and how the plant can manage the spent liquid.

Acid gases rarely occur alone. They usually accompany heat, particulate, or acid mist, and a wet system can handle these contaminants in one train. PCC’s wet scrubber line has more than 1,400 wet scrubber installations, including 300 flue gas desulfurization units. PCC designs the absorber around the entire gas stream, not just the acid gases.

Open spray towers with high, adjustable absorption efficiency at low pressure drop

Spray distributors and nozzles designed to minimize plugging, scaling, and buildup of reacted salts

Packed towers with a wide selection of packing materials for stringent emission limits

Tray scrubbers that absorb acid gas, soluble alcohols and cool the gas in one vessel

Long-term compliance demonstrated against federal MACT and BACT standards

Integrated Train:

  • Quench or venturi for hot gas and particulate ahead of the absorber

  • Spray, packed, or tray acid gas absorber using an alkaline solution

  • High-efficiency mist elimination, with a WESP where acid mist is present

  • Industrial waste incinerator upstream where the acid gas comes from burning chlorinated or sulfur-bearing waste

Contact us by phone at 1 (412) 655-0955 or request an engineering consultation to discuss your acid gas control needs.

Need Information? Tell us your request.

"*" indicates required fields

This field is for validation purposes and should be left unchanged.
Name*
Max. file size: 20 MB.
Would you like to request a quotation?

Why the Gas Chemistry Comes First

The acid gases are regulated differently. SO₂ is a criteria pollutant, and its 1-hour national ambient air quality standard of 75 ppb helps inform source-specific permit limits. HCl and HF are on EPA’s list of hazardous air pollutants, so their limits may be established under applicable NESHAP and MACT standards. One exhaust stream can be subject to both types of requirements.

They also absorb differently. HCl and HF are highly soluble and transfer into the scrubbing liquid readily. SO₂ is less soluble, so its removal depends on maintaining alkalinity in the liquid and providing sufficient gas-liquid contact. Sulfur trioxide (SO₃) is a separate problem: It can form sulfuric acid mist as the gas cools, producing fine droplets that may pass through conventional absorbers and require a dedicated mist removal device or a WESP.

Acid Gas Control Technologies PCC Applies

Technology How Gas and Liquid Meet Best Fit Trade-off
✓ Open spray tower (acid gas absorber line) Scrubbing liquid is sprayed through an open tower with no packing to foul Boiler flue gas desulfurization and HCl removal, HF and SO2 in aluminum production, lime sludge kilns; hot gas and high dust loads Contact comes from spray coverage, so liquid recirculation is the operating cost
✓ Packed tower Gas and liquid flow countercurrent over a packed media bed Incineration exhaust, chlorine, bromine, and fluorine gases, SO2, chemical processing, and odors, at tight emission limits Packing is chosen for the service; heavy particulate is removed ahead of the bed
✓ Tray scrubber Gas bubbles through liquid held on trays Acid gas with particulate, where gas cooling or heat recovery is also needed Medium pressure drop
✓ Type C-V venturi A venturi throat followed by an enhanced cyclonic separator Large particulate and acid gas removed in one unit Fan energy rises with throat pressure drop
✓ Wet electrostatic precipitator (WESP) Charged elecrodes drive mist and fine particles to flushed collecting tubes Acid mist and submicron particulate after the absorber A polishing stage; it does not absorb gaseous acid

Sodium or Lime: Choosing the Reagent

Sodium reagents, such as caustic soda (NaOH) and soda ash (Na₂CO₃), react quickly and form soluble salts, so the tower internals experience less buildup. The trade-off is reagent cost and a dissolved-salt blowdown the plant must treat or discharge. Lime-based reagents are generally less expensive per unit of acid removed, and much of the reaction product can be removed as solids (calcium sulfite or sulfate, calcium fluoride), while calcium chloride stays in solution. The absorber must accommodate slurry handling and potential scaling.

PCC supplies acid gas scrubbing systems using a variety of reagents and combines quench, spray, and absorber stages so that scrubber water can be reused and recirculated where the process allows.

Where PCC Acid Gas Systems Operate

What PCC Needs to Size a System

  • Gas flow, temperature, and moisture content

    (normal and maximum)

  • Each acid gas present and its inlet concentration,

    including SO₃ or acid mist

  • Particulate loading,

    including whether it is sticky, abrasive, or scale-forming (particulate matter control may share the train)

  • Outlet limit for each pollutant

    (concentration, mass rate, or percent removal) and the regulation behind it

  • Reagents already on site

    and any preference among caustic, soda ash, and lime

  • Water availability

    and where the blowdown can go

  • Any existing scrubber that could be modified

Where the gas composition is not fully known or varies widely, an engineering study defines the design basis before equipment is specified. PCC’s scrubber eBook walks through absorber and reagent selection in more detail.
